| Property | Unit | MPET XG210 | MPET XG245 | MPET XG531C | MPET XG533 | MPET XG551 | Test Method | |
|---|---|---|---|---|---|---|---|---|
| Base Film Thickness | ㎛ | 50 | 188 | 50 | 38 | 25 | Micrometer Method | |
| Tensile Strengt | MD | kgf/㎟ | - | - | - | - | - | ASTM D 882A |
| TD | - | - | - | - | - | |||
| Elongation at Break | MD | % | - | - | - | - | - | |
| TD | - | - | - | - | - | |||
| Young's Modulus | MD | kgf/㎟ | - | - | - | - | - | |
| TD | - | - | - | - | - | |||
| Heat Shrinkage | MD | % | - | - | - | - | - | Seoil Method (150℃/30min.) |
| TD | - | - | - | - | - | |||
| Al Thickness | Å | 480 | 480 | 480 | 560 | 460 | Seoil Method | |
| O.D (Optical Density) | - | 2.4 | 2.4 | 2.4 | 2.8 | 2.8 | Seoil Method | |
| Surface Tension (Metallized Side) | dyne/㎝ | - | - | - | - | - | ASTM D 2578 | |
| Gloss (Metallized Side) | 20˚ | % | - | - | - | - | - | ASTM D 523 |
| 60˚ | - | - | - | - | - | |||
